Equipment Introduction
This machine tool is a practical and cost-effective one independently developed and manufactured by our company. It is specially designed for independent rotary cutting factories, sheet metal factories and small printing and paper cutting factories in remote areas where knife sharpening conditions are inconvenient.
This machine tool is equipped with an automatic feed device and an electromagnetic suction cup on the basis of a common machine tool. When the blade is placed on the worktable and the suction cup switch is turned on, the blade will be firmly attached to the worktable, saving the time of pressing the blade with bolts. The blade is ground more smoothly and has a better straight edge. During the grinding process after installing the blade, no manual operation is required and the grinding wheel grinding compensation can be carried out by itself to achieve automatic grinding. Save about 40 minutes of labor.
Applicable to: Small-scale rotary cutting factories, sheet metal factories, and small-scale printing and paper cutting factories.
Parameters Of LMD- MZ6115 Electromagnetic Fully Automatic Knife Sharpener
Maximum Grinding Length | 1550mm |
Worktable Area (Length * Width) | 1550*180mm |
Grinding Wheel Size | 200*100*32mm (Optional) |
Guide Rail | Machine Tool Guide Rail + Wear - Resistant Strip |
Feeding Method | Manual + Mechanical Cam - Screw Jack Automatic Feeding |
Grinding Precision | ≤0.05mm/m |
Working Voltage | 380v |
Grinding Head Transmission Method | Belt Transmission |
Reciprocating Speed of Machine Tool Grinding Head | About 14m/min |
Adjustable Angle of Grinding Head | ±10° |
Adjustable Angle of Worktable | ±90° |
Power of Grinding Head Motor | 3.0KW - 1440r/min |
Power of Lifting Motor | 0.37KW |
Power of Traveling Motor | 0.75KW |
Power of Water Pump Motor | 0.04KW |
Total Power | About: 4.5KW |
Total Weight | About: 1200KG |
Overall Dimensions | About: 3100*1200*1200mm |
| |
| |
